  Tornado V.92 External Modem   More Information
    »User Guide
    »Quick Installation
    »Driver
    »Brochure



Features / Benefits

  • V.92/V.90 56Kbps Internet connectivity
  • Full duplex speakerphone for hands-free operations
  • Full software bundle to give you integrated telephony features
  • Supports Video Conferencing

Package Includes

  • Tornado V.92 External Serial Modem (Intel Chipset)
  • Installation CD with user manual & Multimedia Communication Suite Software
  • RJ-11 Telephone Cable
  • Serial Port Interface Cable
  • Power Adapter

System Requirements

  • 486 or higher with available COM port
  • 8MB system memory
  • CD-ROM drive
  • Available hard disk space
  • DOS, Windows 3.1, Windows 95/98/ME, Windows NT/2000/XP, Linux

Specifications

  • Interface Standards: PC RS-232
  • Fax Compatibility ITU-T: V.17, V.29, V.27ter, and V.21 ch2 Group 3 fax support, CLASS1 & CLASS2
  • Fax Speeds: 14,400, 12,000, 9600, 7200, 4800, 2400, 1200, and 300 bps
  • Data Transmissions (V.90 & K56FIex Technology): Bell 212A and 103
  • ITU-T: V44, V34+, V34, V32 bis, V.32, V23, V.22 bis, V22, and V21
  • Speeds: 56,000 (download), 33,600, 28,800, 26,400, 24,000, 21,600, 19,200,16,800,14,400, 12,000, 9600, 7200, 4800, 2400, 1200, and 300 bps
  • Telephony: Voice -; Playback of voice messages through telephone line and speaker output; Recording of voice messages through telephone line and microphone input. Full-duplex Speakerphone - Adaptive echo cancellation; Microphone volume selection and muting capabilities
  • Video Conference: V.80 compatible with H.324 subsystems
  • Error Correction: MNP 2-4, V/44/V42, LAPM
  • Data Compression: MNP 5, V42bis
  • DTE Speeds (max.): 115,200 bps
  • Operating Modes: Auto dial/answer; auto feature negotiation full duplex
  • Dial Type: Tone and Pulse
  • Test Modes: Analog loop, Digital loop, Remote Digital loop and pattern test
  • Command Set: Industry-standard AT command set, Extended AT Commands, EIA/TIA-578 CLASS1
  • Flow Control: XON/XOFF; CTS/RTS (Software & Hardware)

Remark:Support of V.92 is dependent on the local ISPs.
